TSP Oil Pan; Cast Aluminum Low-profile Retro-fit 5.5-Quart; LS; Polished

LS engines are among the most popular for swaps for their low expense and great power potential. Unfortunately, stock LS oil pans can't always fit where you want them to. That's where TSP's low-profile, retro fit oil pan comes in. Composed of lightweight cast aluminum, it is designed to allow for increased clearance to the ground and chassis. It will fit many GM rear-wheel drive applications originally equipped with a small or big block Chevy engine and factory rear sump pan. Meticulously designed, it will mount perfectly to any wet-sump LS engine and take the stock oil filter.

Additional Attributes:

GTIN: 00843806113372
Baffled: Yes
Gasket Included: Yes
Maximum Stroke: 3.62
Oil Filter Location: Stock
Oil Pan Finish: Polished
Oil Pan Material: Aluminum
Oil Pick-up Included: Yes
Prop 65 (C, R or CR): CR
Prop 65 – Short Label: prop65_warning.jpg
Prop 65 Flag: Yes
Sump Depth: 5.89
Sump Location: Rear
Sump Oil Capacity: 5.5 Quarts
Sump Style: Wet
Total Oil Capacity: 6.0 Quarts with Stock Oil Filter
Windage Tray Included: No

Extended Information:

Life Cycle Status: Available To Order

Packaging:

Quantity of Each: 1
Package UOM: EA
Dimension: 13 x 25 x 7 inches
Weight: 16 PG
