Engine Complete Assembly

Edelbrock part #46040 E-Force Performer RPM Supercharged small-block Chevy 350 crate engine offers the best of quality and performance right out of the crate. This engine produced 518 horsepower, 500 ft-lbs. of torque on 91-octane pump gas with 6 psi of boost. This supercharged engine is 100% brand new and includes a 4-bolt main short block, Edelbrock E-Tec 200 heads, Rollin' Thunder hydraulic roller camshaft, roller rocker arms, E-Force Supercharger with EPS 600 cfm carbs and long water pump. Engine Specifications: – Finish: Satin – Displacement: 350 c.i.d. – Horsepower: 518 hp – Torque: 500 ft-lbs. – Compression: 9.5:1 – Block: New 4 bolt main with 1-piece rear seal – Crankshaft: Forged steel – Pistons: Hypereutectic – Camshaft: Rollin' Thunder Hydraulic Roller #2205 – Rocker Arms: 1.5:1 Roller #77770 – Supercharger: Edelbrock E-Force #1516 – Cylinder Heads: E-Tec 200 #60985 – Carburetor: (2) 600 cfm Performer Carbs – Distributor: Included – Valve Covers: Cast aluminum – Classic Series – Warranty: 2-year / Unlimited mileage

Additional Attributes:

GTIN: 00085347460403
Air Cleaner Type: Not Included
Camshaft Type: Rollin’ Thunder, Hydraulic Roller
Carburetor Choke Type: (Optional) Electric
Carburetor Type: (Optional) Performer 600 CFM, Satin
Compression Ratio: 9.5:1
Construction Type: Assembled
Crankshaft Material: Forged Steel
Cylinder Head Material: Aluminum
Cylinder Head Type: E-Tec 200
Displacement: 350
Distributor Included: Yes
Engine Block Material: Cast Iron
Flywheel Included: No
Grade Type: Performance
Hardware Included: Yes
Harmonic Balancer Included: Yes
Horsepower: (Carb) 518/(EFI) 519
Intake Manifold Type: Not Included
Main Bearing Cap Bolt Quantity: 4-Bolt
Manifold Material: N/A
Oil Filter Included: Yes
Oil Pan Included: Yes
Outside Pulley Diameter: 4.125
Piston Type: Hypereutectic Aluminum
Plug Wire and Boot Included: No
Pulley Belt Width: 10-Rib
Pulley Finish: Satin
Quantity: Sold Individually
Rear Main Seal Type: 1-Piece
RGL: WARNING: This product can expose you to Chromium, Lead, and Zinc which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov.
Rocker Arm Ratio: 1.5:1
Rocker Arm Type: Roller
Rotor Type: Eaton TVS 2300, Satin
Spark Plugs Included: No
Throttle Body Included: (Optional) (2) 1000
Timing Cover Included: Yes
Torque: (Carb) 500/(EFI) 507
Type: Small-Block Chevy
Universal Or Specific Fit: Specific Fit
Valve Cover Included: Yes
Valve Cover Material: Cast Aluminum
Valve Cover Type: Classic, Standard Profile, Satin
Water Pump Included: Yes, Long Pump
Wire Harness Included: No

Extended Information:

Emissions : EPA Eligible
Life Cycle Status: Obsolete

Packaging:

Quantity of Each: 1
Package UOM: EA
Dimension: 48 x 40 x 45 inches
Weight: 600 PG

PDF:

46040
