BluePrint Engines GM LS Compatible 427 c.i. Engine and 4L65/70E Automatic Transmission – Standard Edition Builder Series – Holley Terminator X EFI System

BluePrint Engines 427 c.i. GM LS Compatible Builder Series – Standard Edition – Fuel Injected – 4L65/70E Automatic Transmission. Includes 30-Month / 50,000 Mile Warranty & Dyno Tested

Additional Attributes:

GTIN: 00887753986412
Air Cleaner Included: No
Block Description: BluePrint Engines High Strength Cast Iron (LSX Style) Block – 6 Bolt Main – 4.0665″ Bore
Cam: Hydraulic Roller – .624 Intake / .624 Exhaust Lift – 239 Intake / 255 Exhaust Duration -@.050-114 LSA
Carb/Fuel Injection Included: Yes
Compression Ratio: 11.0:1
Crankshaft Vendor: BluePrint Engines
Cylinder Head Vendor: BluePrint Engines
Cylinder Heads Included: Yes
Cylinder Heads: LS3 Aluminum Cylinder Heads
Distributor Included: Coil Packs
Distributor Vendor: BluePrint Engines
Engine Balance: Internally Balanced
Firing Order: 1,8,7,2,6,5,4,3
Flexplate/Flywheel Included: Yes
Fuel Delivery Type: Fuel Injected
Fuel Delivery Vendor: Holley Terminator EFI
Fuel Pump Included: No
Harmonic Balancer Included: Yes
Horsepower: 625
Intake Manifold Included: Yes
Intake Manifold Type: BluePrint Engines Cast Aluminum Intake
Intake Manifold Vendor: BluePrint Engines
Oil Pan Included: Yes-Rear Sump
Pistons: Forged
Prop 65 Y/N Flag: Yes
Pulley Kit Included: No
Quantity: EA
Rear Main Seal Style: 1 Piece
Recommended Flexplate/Flywheel: Non Weighted BPP12654640 – BPPLS1611
Recommended Harmonic Balancer: Non-Weighted
Recommended Octane Fuel: 91+ Octane
Recommended Spark Plug Gap: .045 in.
Recommended Spark Plug: CCH9405
Recommended Stall Converter: 2200+ RPM
Rotating Assembly: Forged Crank – 4.125 in. Stroke and Forged 6.125 in. Rods
Spark Plug Wires Included: Coil Packs
Spark Plugs Included: Yes
Timing Cover Included: Yes
Timing Requirements: ECM Supplied with Calibration
Torque: 565
Transmission Model: 4L65/70E
Transmission Type: Automatic
Valve Covers Included: Yes
Water Pump Included: Yes

Extended Information:

Emissions : Racing or Pre-Emissions Use Only
Life Cycle Status: Available To Order

Packaging:

Quantity of Each: 1
Package UOM: EA
Dimension: 60 x 30 x 30 inches
Weight: 750 PG

PDF:

LS ENGINE INSTALLATION GUIDE (3)
