Big Victor 498cc CNC 12 Degree 2.500″ x 1.800″

Edelbrock introduces its new Big Vic CNC 12-degree race head, specifically designed for maximum competition naturally aspirated, nitrous injected, and boosted applications. The Big Vic 12 is cast in the USA at Edelbrock's state-of-the-art foundry, using a premium aluminum alloy that undergoes hot isostatic pressing for a more stable and dense grain structure. The large CNC oval ports and 2.500 x 1.800 valve job are specifically designed to maintain high airspeed for maximum cylinder fill during valve opening and generate a high torque curve throughout the engine's operating range. Manufactured with premium materials and machined to the industry's tightest tolerances, these heads feature a 12-degree valve angle, copper valve seats, and fully CNC-machined 498cc ports and 82cc chambers to increase overall airflow capability. The premium manganese bronze valve guides withstand long wear with emphasis placed on holding precise tolerances on valve seat concentricity, allowing the valves to seal securely to eliminate leak-down and increase cylinder pressures during engine operation.

Additional Attributes:

GTIN: 00085347897476
Material: Aluminum
Guide Plates Included: No
CNC Machined Combustion Chamber: Yes
CNC Machined Exhaust Port: Yes
CNC Machined Intake Port: Yes
Combustion Chamber Volume: 82cc with Conical Design and Titanium valves
Cylinder Head Style: Bare
Exhaust Port Location: Raised _x000D_
Exhaust Port Shape: D Port
Exhaust Valve Job Diameter: 1.800″
Exhaust Valve Stem Diameter: 11/32″
Intake Port Location: Raised and Spread
Intake Port Shape: Oval
Intake Runner Volume: 498
Intake Valve Job Diameter: 2.500″
Intake Valve Stem Diameter: 11/32″
Quantity: Single
Rocker Arm Studs Included: No
Spark Plug Style: 14mm Gasket Seat .750″ reach
Steam Holes Drilled: Yes
Valve Angle: 12
Valve Cover Mounting Style: BBC
Valve Guide Inside Diameter: 11/32″
Valve Guide Material: Mag Bronze
Valve Guide Size Outside Diameter: 0.502
Valve Spring Type: Bare

Extended Information:

Emissions : EPA Eligible
Life Cycle Status: Available To Order

Packaging:

Quantity of Each: 1
Package UOM: EA
Dimension: 26 x 11 x 9.5 inches
Weight: 43.4 PG
