Aldan American Coil-Over Kit, Chevy Road Comp Series Coilover Kits – 300385

We offer dozens of universal coilover and shock absorbers with various mounts, valving and ride-height options. These are great for custom chassis and custom suspensions like 4-links and IFS kits. For vehicle specific applications, we offer thousands of combinations of 100% bolt-on solutions to upgrade to adjustable coilovers and shocks. Other shock accessories like control arms, sway bars, thrust bearings and more are available from Aldan American.

Additional Attributes:

GTIN: 00799793165026
Adjustable Mounting Bracket Included: No
Adjustable Valving: Yes
Body Diameter: 2
Bushing Color: Black
Bushing Material: Polyurethane
Coilover Springs Included: Yes
Collapsed Length: 10.750 front, 13.000 rear
Crossmember Included: No
Extended Length: 14.300 front, 18.000 rear
Gas Charged: Yes
Hardware Included: Yes
Internal Design: Twin-tube
Lower Mount: Bar pin, front; Eyelet, rear
Notes: A front Sway Bar relocation kit is required – Sold Separately.
Number of Valving Selections: 6 Front, 11 Rear
Prop 65 (C, R or CR): CR
Prop 65 – Short Label: WARNING: Cancer and Reproductive Harm-www.p65warnings.ca.gov
Prop 65 Yes/No: Yes
Shock Body Finish: Natural
Shock Body Material: Aluminum
Shocks Included: Yes
Spring Finish: Black powdercoated
Spring Rate (lbs/in): 500 lbs./in. Front, 500 lbs./in. Rear
Suspension Height Adjustment: 0.0-2.0 in. Lowered Front; 0.0-2.0 in. Lowered Rear
Threaded Adjustment Range: 5.000 in front, 5.000 in rear
Upper Mount: Stud, front; Eyelet, rear
Welding Required: No

Extended Information:

Emissions : 4
Life Cycle Status: Available To Order

Packaging:

Quantity of Each: 1
Package UOM: KT
Dimension: 16 x 9 x 24 inches
Weight: 45 PG

PDF:

X-0015, One Piece Spring Retainer Instructions
