Complete wiring diagram and delay setting tips included.
Setting the box Is quick and easy with three sets of pushbutton thumbwheels.
Built in toggle switch allows you to cancel the cross-over feature and act as a standard delay box in the event that you are matched against a faster opponent.
Mountable in any position, even upside down for overhead locations. Measures 10.63 in. W x 3.38 in. H x 1.25 in. D
No special wiring or batteries required.
Dedenbears Exclusive Ignition Noise Filters Permit Use With Solid Core Plug Wires And All Types Of Ignition Systems, Including Magnetos!
Dedenbears Quartz Crystal Timer Ensures Optimum Accuracy Under All Conditions.
Early release protection standard.
Full 12V to transbrake with no voltage drop through the delay box
LIGHTNING PLUS, LARGE DISPLAY BILLET SUPER DELAY BOX W/ MULTIPLE OUTPUTS
$ 1,063.64
250% Larger viewable display area than the original Lighting delay box.
Pro/Full feature allows saving two groups of settings
Billet aluminum enclosure with lighted keypad and display for night use measures 8.73 in. W x 2.95 in. H x 1.85 in. D
4 delay modes include: Cross-Talk, Crossover, Interface, and Delay
Skip up and skip down (same as tap up/down to add or subtract from your delay with the push of a separate button after you release the transbrake button)
Two 4-stage timers, adjustable to the thousandth (ideal for throttle stops, shift by time, nitrous, lean outs and retards)
Adjustable transbrake lockout, Crossover Compensation and Trip Protection
Independent line lock output
Starting line control output with adjustable time release
Super Start Automatic Starting Line Control For Activating A Throttle Stop Prior To Staging
LIGHTNING, BILLET SUPER DELAY BOX WITH MULTIPLE OUTPUTS
$ 1,025.18
Billet aluminum enclosure with lighted keypad and display for night use measures 7.23 in. W x 2.95 in. H x 1.85 in. D.
12 and 16 Volt system compatible
4 delay modes include: Cross-Talk, Crossover, Interface, and Delay
Skip up and skip down (same as tap up/down to add or subtract from your delay with the push of a separate button after you release the transbrake button)
Two 4-stage timers, adjustable to the thousandth (ideal for throttle stops, shift by time, nitrous, lean outs and retards)
Adjustable transbrake lockout, Crossover Compensation and Trip Protection
Independent line lock output
Starting line control output with adjustable time release
Super Start Automatic Starting Line Control For Activating A Throttle Stop Prior To Staging
Pro/Full feature allows saving two groups of settings
Billet aluminum enclosure with lighted keypad and display for night use. Measures 8.25 in. W x 3.95 in. H x 1.4 in. D.
12 and 16 Volt system compatible
NHRA accepted for use in all electronic classes
4 delay modes include: Cross-Talk, Crossover, Interface, and Delay
Skip up and skip down (same as tap up/down to add or subtract from your delay with the push of a separate button after you release the transbrake button)
Remote display output for LED dial-in board RD1
Independent line lock output
Adjustable transbrake lockout
Crossover compensation and Trip Protection
Pro/Full feature allows saving two groups of settings
